Aluminum Buttweld

View All

  • Aluminum Buttweld Elbows conform to ASM 6061-T6.
  • Stocked in sizes from 1" to 6".

Three different Aluminum Buttweld Elbows
Sizes are Nominal Pipe Size (NPS) - size chart
Two Aluminum Buttweld Elbows in different sizes.

To start, select size. Follow the green box to refine selections as desired. Click “Lookup Product” any time after selecting size to display products matching criteria entered so far. Fields autofill when only one choice. Or use search box above.


Schedule refers to the pipe thickness on which this fitting is to be used, typically values are STD (standard), S/10 (Schedule 10) and XH (extra heavy). These thickness vary with the diameter of the pipe according to published standards.


Domestic = Made in the USA

Import = Made anywhere else


Long Radius = radius is 1.5 times pipe diameter.

Short Radius = radius is the same as the pipe diameter.

Street 90 = female threads one end, male threads the other.
